Specifications
Specifications
- Speaker Type – In Wall 2-Way
- Woofer – Dual 4″ Fluted Injected Poly
- Tweeter – 1″ Aluminum Dome
- Frequency – 62 Hz – 24 kHz
- Sensitivity – 92db
- Butyl Rubber Surround
- Sonic Vortex® Ported Transmission Line
- Magnetic Bezelless Grille – White; paintable
- Impedance – 6Ω
- Connector Type – Gold Spring Push Terminal
- Depth – 2.82″ (71.5mm)
- Speaker Weight – 6 lbs (2.72kg)
- Cutout – 18.31″ H x 8.74″ (465mm x 222mm)
- Grille Dimensions – 19.62″ H x 10.06″ W (498mm x 255.4mm)
- Frequency/Crossover Setting – Full range only
- Power Handling – 5-120W
- EZBracket Size – Does not apply
- Highlights – Ultra Shallow Depth Pancake Less than 3″ Depth (71.5mm)
