Specifications
Specifications
- Speaker Type – In Ceiling/In Wall 2-Way
- Woofer – 4″ Fluted Injected Poly
- Tweeter – 3/4″ Aluminum Dome
- Frequency – 62 Hz – 24 kHz
- Sensitivity – 88db
- Butyl Rubber Surround
- Sonic Vortex® Ported Transmission Line
- Magnetic Bezelless Grille – White; paintable
- Low Impedance – 8Ω
- 25V Taps – 0.2, 0.3, 0.5, 0.9, 1.8 Watts
- 70V Taps – 1, 1.9, 3.8, 7.5, 15 Watts
- 100V Taps – 1.9, 3.8, 7.5, 15 Watts
- Connector Type – Four position plug-in screw terminal
- Power Handling – In 8Ω Mode 5-80W
- Speaker Weight – 2.93 lbs (1.33kg)
- Cutout – 8.4″ (162mm)
- Diameter – 9.5″ (241.4mm)
- Depth – 2.76″ (70.2m)
- EZBracket Size – F
- Highlights – 25/70/100 Volt Switchable – Ultra Shallow Depth Pancake Less Than 3” (70mm)
