Specifications
Specifications
- Speaker Type – In Wall 2-Way
- Woofer – Dual 4″ Carbon Fiber
- Tweeter – 1″ Titanium Dome
- Frequency – 59 Hz – 25 kHz
- Sensitivity – 92db
- Butyl Rubber Surround
- Sonic Vortex® Ported Transmission Line
- Magnetic Bezelless Grille – White; paintable
- Impedance – 6Ω
- Connector Type – Gold Spring Push Terminal
- Depth – 2.82″ (71.5mm)
- Speaker Weight – 5.95 lbs (2.7kg)
- Cutout – 18.31″ H x 8.74″ W (465mm x 222mm)
- Grille Dimensions – 19.62″ H x 10.06″ W (498.4mm x 255.4mm)
- Frequency/Crossover Setting – Full range only
- Power Handling – 5-120W
- EZBracket Size – Does not apply
- Highlights – Ultra Shallow Depth Pancake Less than 3″ Depth (71.5mm)
